M4KSA Sanitary Sampler
Get Started
Request A QuoteNot What You're Looking For?
Contact UsDesigned for milk, whey, and pharmaceutical sampling, the ISOLOK M4KSA sanitary sampler ensures that your samples are representative of your entire process.
This automatic sampler is easy-to-clean and streamlined. The ISOLOK sampler's design uses compressed air and a controller to sample at a receiving dock or on pressure lines for accurate butterfat content of raw milk or other applications that need to avoid contamination.
- Small body bore diameter and sanitary O-ring design.
- ISOLOK M4KSA sanitary sampler users report major savings in required agitation time as well as the elimination of manual sampling from receiving tanks.
- The simple hygienic design comes with a sanitary quick disconnect tri-clamp mounting suitable for any line size.
Temperature
- ISOLOK M4KSA ambient operating temperature -5˚ to 131˚F (-20˚ to 55˚C), depending on the seal material.
- The sample material temperature can be -40˚ to 500˚F (-40˚ to 260˚C), depending on seal material and duty cycle.
Pressure
- The M4KSA sampler can handle up to 150 PSI (10.3 bar) process pressure.
- Contact our team if higher pressures are needed.
8.25 in x 3 in (21 cm x 8 cm)
Related Resources
Learn more about how the M4KSA Sanitary Sampler can benefit your application with the following resources.
Instruction Manuals
ISOLOK M4KSA Sampler IOM
Spec Sheets
ISOLOK M4KSA Sampler Spec Sheet
Marketing Materials
Automatic Sampler Brochure
Application Guides
Liquid and Slurry Application GuideNeed Something Else?
