Spiral Tube Heat Exchanger
Get Started
Request A QuoteStill Have Questions?
Contact UsMaintain heat transfer efficiency and maximize your plant footprint with our compact, lightweight Spiral Tube Heat Exchanger.
The heat exchanger’s coil assembly is versatile for several applications such as:
- Pump seal coolers
- Sample coolers
- Inter/after coolers
- Acid heaters/coolers
- Instant hot water heaters
- Process condensers
The efficiency of this spiral heat exchanger can be found in its parallel tube configuration ensuring that you are maximizing space and your flow rates.
- Meet robust sample conditions – The spiral heat exchanger can withstand pressures up to 5000 psi (345 bar) and temperatures up to 1000°F (540°C).
- Enhances heat transfer on both sides with a true counterflow arrangement.
- Doesn’t require tube supports or pass dividers to function.
Pressure and Temperature Rating
- Spiral coil rated up to 5000 PSI at 1000°F (345 bar at 538°C)
- Spiral shell rated up to 450 PSI at 650°F (31 bar at 343°C)
- Pressure and temperature ratings are dependent on material selection and heat exchanger size.
Material
- Painted carbon steel shell available standard
- 304/304L and 316/316L stainless steel shell options available
- 316/316L stainless steel coil available standard
- Alloy 625 coil option available
- Contact us for additional material options
ASME Code Stamp Available
Surface Area
- 1 to 177 ft2 (0.1 - 16 m2)
